Paspatoo offers two staterooms and two full-sized custom vacuum head systems.

Her owners will feel right at home in the full-beam master cabin below decks. Paspatoo is a fully-customized yacht offering a walk-around queen berth, large seating area, desk, and entertainment center with Flat Panel HDTV and surround-sound.

Paspatoo's current owner spares no expense in keeping her extremely well maintained and in Bristol condition. He has put great thought into her well-being. The systems, which have been added make her a first class custom wooden classic yacht with modern amenities

The deck level wheelhouse has a full width helm station. Port & Starboard doors lead out to the side decks. Next aft is the main salon with a U-shaped galley and large dinette giving a casual grand room feel. The passageway to port leads to the on deck level master cabin with double berth and en-suite head and generous built in storage and hanging locker cabinetry. A door leads aft to the back deck and hot tub area. Stairs aft of the main salon lead below deck to a short passageway.

Forward is the second cabin and media entertainment salon. A large berth along with seating are arranged for relaxation and enjoying a movie on the flat screen home movie entertainment center. Elegant woodwork and cabinetry give this area a warm rict feel. The adjacent head with full size bath tub are user friendly as the fixtures are comparable to those seen in a residential application, or as you would encounter on a luxury cruise liner.


Aft leads to the utility area with washer/ dryer, electrical panel access and work bench. Next is the door to the engine room, lazarette access to main generator and underbody of below deck hot-tub.

The galley is bright with storage and counter space that rivals most residential kitchens. Beautiful cabinetry, counter tops and double stainless steel sink. The full size side by side Frigidaire Euro-flare refrigerator/ freezer and Gaggeneau four-burner range with electric oven will satisfy the needs of the most demanding chef. Complete with microwave oven, dishwasher and combo laundry machine, trash compactor and central vacuum, life at sea is not without creature comforts to enhance the experience.

On the exterior teak decks, the foredeck has a Maxwell hydraulic windlass and custom built teak skylight that brightens the master stateroom. From the bow, walking aft down the wide gunwales you’ll appreciate the incredible teak caprails and bronze hardware, you’ll then enter the aft deck where a 180’ view can be soaked in. Speaking of “soaked in” you can also soak yourself in the custom teak 4 person hot tub, in your choice of fresh or salt water.

Also equipped on the aft deck is mounts for up to 8 scuba tanks and a pneumatic connection to recharge your scuba tanks from the onboard scuba compressor that also provides pneumatic connections through the vessel. From the aft deck, you can swim or scuba dive from the easily accessible teak swim platform.

From the port side gunwale, you can step up the beautiful teak stairs that brings you to the flybridge. The Flybridge provides one of three vessel operating stations, a large 6-8 person settee, a well equipped bar and an open large deck for more lounging space, tenders, toys, storage and more.

Equipped with

COOKING: Gaggenau electric four burner stove with oven. Sharp convection/microwave.

REFRIGERATOR/FREEZER: Frigidair Euroflare refrigerator/freezer in galley. Vitiligo refrig and freezer at bar on upper deck.

GALLEY SINK: Porcilin double sink in galley, stainless sink at upper bar.
PRESSURE WATER SYSTEM: Electric pumps
WASTE DISPOSAL: Kitchen Aid compactor
DISHWASHER: Miele dishwasher
WASHER/DRYER: Frigidair laundry combo wash/dry.

VACUUM SYSTEM: Two closet mounted central vacuum systems, vacuum connections on upper and lower decks.

HEADS: Forward and aft toilets are vac flush systems

SHOWER: Full bath with shower in forward head.
Outdoor shower located on aft deck

HEATING SYSTEM: HVAC is provided with dual Aqua Air air-conditioning units and heating is with two Webasto diesel fired hydronic heaters. All diesel-fired machinery is protected with Racor fuel filtration systems

WATERMAKERS: Two Spectra water-makers; Newport 1000c 41gallons pr hr, 1000gallons daily

HOT TUB: Teak custom hot tub installed in aft deck with teak deck cover. Tub has own water heater filtration system. Hot water can be supplied by hydraunic systems or electric. Water can be fresh or salt.

WHEEL: Hydraulic wheel steering from pilothouse. Remote steering controlled at aft deck, which operates thruster, transmission and engine.

STABILIZERS: Naiad, model 301 hydraulic active fin stabilizers.

FUEL SYSTEM: 1300-gallon; stainless steel fuel tanks is located on port side of engine room. Tanks have visual sights and electric gauge. Additional 300gal auxiliary tanks.

FRESH WATER SYSTEM: 350-gallon stainless tank mounted in forward end of hull.

HOT WATER TANK: Two Ever-hot All-Copper water heaters, can be heated by hydraunic heaters or electric.

Hull

Hull; constructed of old growth Douglas fir planks. Carvel planking is 9"x 2 ½"on hull below waterline, hull sides are 4"x 2 ½" planks. Planking is fastened to 3"× 3" oak frames, which are on 12"centers.

Planking fastened with pine tar dipped #20 x 3.5” galvanized fasteners, refastened 6/2024. Floors and stringers are bolted to framing. The hull has inner planking on hull.

On the exterior of hull, planking is in excellent condition and no signs of weepage sighted at fastener locations Planks are not proud of each other and butt ends are in prefect condition.

Aft of the long keel is an iron foot, which carries the load of the rudder. This is securely fastened to the bottom or the keel with bolts. At the stem, the timber is jointed to forefoot and keel with metal strap forming a gripe plate to strengthen stem to keel joint.


The planking is well hooded into the rabbet of stem post. Large rub rail timber is attached to hull just below the shear. Ironwood is used on starboard bow to protect hull from anchor.

Specs

Make/model: Blanchard, custom
Year: 1942
LOA: 66’ 9”
Beam: 18’
Draft: 6’ 6”
Fuel tankage: 1300 gallons, stainless tank
Water tankage: 359 gallons, stainless tank
Black water: 80 gallons
Main engine/hrs: 6v92, 1900hrs
Transmission: Hundested, controlled pitch gearbox
Thruster: Arcturus 120, hydraulic bow thruster
Gensets: 15kw & 30kw, Northern Lights

Equipped with, continued

WASTE SYSTEM: 80-gallon vac tank mounted in machine area, lactated in engine control room.

Permanently engraved dead-front AC & DC breaker panels. Stranded marine grade copper wiring throughout.All wiring is labeled and very neatly done.D/C: Batteries supply 12-volt and 24-volt systems.A/C: Gensets supply the 120/240v or the dockside outlets for 50-amp 120/240v connections. There is also capability to connect to 120/30-amp shore power also.


GEN/SET: The main power generation is with an 30kw generator in a sound shield, along with a 15kw auxiliary, or "night" generator.

INVERTERS: Two Victron MultiPlus-II SW 24v 3000-watt inverter/chargers with independent battery banks. The Victron inverters are tied into Victrons latest Ekron GX monitoring/control system with endless possibilities of connecting additional technology such as remote smart phone monitoring. Professionally installed 3/2024.

BATTERIES: Six 12-volt 8D batteries, wired for 24-volts are mounted securely in aft engine room space. There are six more 12-volt 8D batteries mounted under the settee bench of forward stateroom. Another independent starting battery bank. Also there is another independent battery bank in the pilothouse for navigation equipment. All batteries are new, professionally installed 1/2024.

BATTERY CHARGER: The Victron invterters are also chargers, for redundancy there are also two Mastervolt 24 100-amp aux chargers. TrueCharge-20 12v and Charles 20-amp 12v marine battery chargers for pilothouse bank.

BONDING SYSTEM/CATHODIC PROTECTION: Electroguard 500 and 601 bonding system. Also equipped with two isolation transformers.

Electronic comm/navigation equipment-
COMPASS: Ritchie compass at helm is in good condition.
DEPTH SOUNDER: Raymarine ST60 at each helm and LS-4100 at main helm.
VHF RADIO: Horizon VHF at main helm. Two Horizon Triton plus VHF's, one at each helm. Hailer/Fog at main helm. SSB radio at main helm.
GPS/CHART PLOTTER: Two Lenovo laptops operating Rose Point navigation programs. Also Lenovo for upper helm.
RADAR: Two open array Radars, one is 21-mile the other is 24-mile.
AUTOPILOT: Simrad and Raymarine autopilots

Ground tackle-
ANCHOR: 250lb Navy anchor with 480' 9mm chain on bow. Fortress aluminum anchor with 3/8" chain and ¾" rode used for stern anchor.
WINDLASS: Maxwell 4500 hydraulic anchor windlass is horizontal mounted in deck. Commercial quality with Navy style anchor in hawse-pipe

-EXTINGUISHERS: Six hand held extinguishers are place through out vessel. One in engine room is Halon, others are Dry. Kiddie Model 1301 automatic fire extinguisher is mounted in engine room.

Dewatering system-
-BILGE PUMP(s): Two Jabsco 1150 GPH bilge pumps with auto float switches. Pacer 5 hp hydraulic pump, rated at 280 GPH mounted in engine room.

DINGHY: 1990 AVON, Hard bottom rib with console seating and electric start. Good condition.
OUTBOARD: Honda, model BF30A. 30hp four stroke

DAVIT: Davit on upper deck for launching tender, davit can also be remounted fwd to load supply
